iQontrol – Eine einfache VIS für alle Geräte

Oft bekomme ich das Feedback, dass die VIS für den ioBroker zu kompliziert ist und zu lange benötigt, bis man diese eingerichtet hat. Das stimmt natürlich auch – aber dafür ist sie auch unglaublich flexibel!

Aber für die Visualisierung auf dem Handy nutze ich selbst auch eher iQontrol. Der Vorteil hierbei ist, dass ich ziemlich schnell neue Geräte und Daten integrieren kann, um hierauf zugreifen zu können. Auch hier kann ich Wetterdaten, Diagramme, Kameras usw. einbinden, sodass ich auf nichts verzichten muss. Der Vorteil ebenfalls ist, dass das iQontrol responsive ist und somit auf allen Geräten funktioniert.

Grundlegende Einrichtung – Die ersten Schritte

Die Installation im ioBroker ist einfach wie immer. Einfach den Adapter installieren – das war’s auch schon. Die Einrichtung bzw. ersten Schritte im iQontrol fand ich selbst etwas schwieriger. Wenn man allerdings das System erst einmal verstanden hat, dann ist es wirklich einfach und schnell gemacht!

Zur Einrichtung habe ich natürlich auch ein Video erstellt – hier erkläre ich Dir alle Schritte, die Du wissen musst:

Weitere Daten einbinden

Es lassen sich aber auch viele weitere Daten einbinden, die Du über iQontrol einsehen und steuern kannst. Im Video zur Einrichtung hatte ich Euch Zuschauer aufgerufen, mir einmal zu sagen, was genau ihr Euch wünscht.

Genau auf diese Themen gehe ich nun hier im zweiten Video ein. Ich zeige Euch, wie Wetterdaten, Diagramme, Kameras, Links zu externen Seiten und Datenpunkte weiterer Daten eingebunden werden können.

Beispielgeräte für Dich zum Importieren

Wie im Video angesprochen, lassen sich diese Geräte auch exportieren und importieren. Wichtig ist hier natürlich, dass die Datenpunkte angepasst werden!

Hier die Geräte:

Kamera Einbindung:

[{"commonName":"Kamera","nativeNewLine":false,"nativeHeading":"","nativeHeadingOptions":"","nativeLinkedView":"","nativeBackgroundImage":"","nativeBackgroundImageActive":"","nativeHide":false,"commonRole":"iQontrolValue","states":[{"state":"STATE","commonRole":"linkedState","value":""},{"state":"LEVEL","commonRole":"linkedState","value":""},{"state":"INFO_A","commonRole":"array","value":"[]"},{"state":"INFO_B","commonRole":"array","value":"[]"},{"state":"BATTERY","commonRole":"linkedState","value":""},{"state":"UNREACH","commonRole":"linkedState","value":""},{"state":"ERROR","commonRole":"linkedState","value":""},{"state":"BACKGROUND_VIEW","commonRole":"const","value":""},{"state":"BACKGROUND_URL","commonRole":"const","value":""},{"state":"BACKGROUND_HTML","commonRole":"const","value":"<html style=\"height: 100%;\"><head><meta name=\"viewport\" content=\"width=device-width, minimum-scale=0.1\"></head><body style=\"margin: 0px; background: #424242; height: 100%\"><img style=\"-webkit-user-select: none;max-width: 100%;\" src=\"http://192.168.178.161/mjpegstream.cgi?-chn=12&-usr=admin&pwd=XXXXXXXXX\"></body></html>"},{"state":"ENLARGE_TILE","commonRole":"linkedState","value":""},{"state":"BADGE","commonRole":"linkedState","value":""},{"state":"BADGE_COLOR","commonRole":"const","value":""},{"state":"OVERLAY_INACTIVE_COLOR","commonRole":"const","value":""},{"state":"OVERLAY_ACTIVE_COLOR","commonRole":"const","value":""},{"state":"GLOW_INACTIVE_COLOR","commonRole":"const","value":""},{"state":"GLOW_ACTIVE_COLOR","commonRole":"const","value":""},{"state":"GLOW_HIDE","commonRole":"linkedState","value":""},{"state":"URL","commonRole":"const","value":""},{"state":"HTML","commonRole":"const","value":""},{"state":"ADDITIONAL_CONTROLS","commonRole":"array","value":"[]"},{"state":"ADDITIONAL_INFO","commonRole":"array","value":"[]"}],"options":[{"option":"icon_on","type":"icon","value":"./images/icons/blank.png"},{"option":"icon_off","type":"icon","value":"./images/icons/blank.png"},{"option":"readonly","type":"checkbox","value":"false"},{"option":"renderLinkedViewInParentInstance","type":"checkbox","value":"false"},{"option":"renderLinkedViewInParentInstanceClosesPanel","type":"checkbox","value":"false"},{"option":"clickOnIconAction","type":"select","value":"openDialog"},{"option":"clickOnTileAction","type":"select","value":"enlarge"},{"option":"noZoomOnHover","type":"checkbox","value":"true"},{"option":"iconNoZoomOnHover","type":"checkbox","value":"true"},{"option":"hideDeviceName","type":"checkbox","value":"false"},{"option":"tileActiveStateId","type":"text","value":""},{"option":"tileActiveCondition","type":"select","value":""},{"option":"tileActiveConditionValue","type":"text","value":""},{"option":"sizeInactive","type":"select","value":""},{"option":"stateHeightAdaptsContentInactive","type":"checkbox","value":"false"},{"option":"stateFillsDeviceInactive","type":"checkbox","value":"false"},{"option":"stateBigFontInactive","type":"checkbox","value":"false"},{"option":"bigIconInactive","type":"checkbox","value":"false"},{"option":"iconNoPointerEventsInactive","type":"checkbox","value":"false"},{"option":"transparentIfInactive","type":"checkbox","value":"true"},{"option":"noOverlayInactive","type":"checkbox","value":"true"},{"option":"hideBackgroundURLInactive","type":"checkbox","value":"false"},{"option":"hideDeviceNameIfInactive","type":"checkbox","value":"false"},{"option":"hideStateIfInactive","type":"checkbox","value":"false"},{"option":"hideIndicatorIfInactive","type":"checkbox","value":"false"},{"option":"hideInfoAIfInactive","type":"checkbox","value":"false"},{"option":"hideInfoBIfInactive","type":"checkbox","value":"false"},{"option":"hideDeviceIfInactive","type":"checkbox","value":"false"},{"option":"sizeActive","type":"select","value":""},{"option":"stateHeightAdaptsContentActive","type":"checkbox","value":"false"},{"option":"stateFillsDeviceActive","type":"checkbox","value":"false"},{"option":"stateBigFontActive","type":"checkbox","value":"false"},{"option":"bigIconActive","type":"checkbox","value":"false"},{"option":"iconNoPointerEventsActive","type":"checkbox","value":"false"},{"option":"transparentIfActive","type":"checkbox","value":"true"},{"option":"noOverlayActive","type":"checkbox","value":"true"},{"option":"hideBackgroundURLActive","type":"checkbox","value":"false"},{"option":"hideDeviceNameIfActive","type":"checkbox","value":"false"},{"option":"hideStateIfActive","type":"checkbox","value":"false"},{"option":"hideIndicatorIfActive","type":"checkbox","value":"false"},{"option":"hideInfoAIfActive","type":"checkbox","value":"false"},{"option":"hideInfoBIfActive","type":"checkbox","value":"false"},{"option":"hideDeviceIfActive","type":"checkbox","value":"false"},{"option":"sizeEnlarged","type":"select","value":"xwideIfEnlarged highIfEnlarged"},{"option":"stateHeightAdaptsContentEnlarged","type":"checkbox","value":"false"},{"option":"stateFillsDeviceEnlarged","type":"checkbox","value":"false"},{"option":"stateBigFontEnlarged","type":"checkbox","value":"false"},{"option":"bigIconEnlarged","type":"checkbox","value":"false"},{"option":"iconNoPointerEventsEnlarged","type":"checkbox","value":"false"},{"option":"transparentIfEnlarged","type":"checkbox","value":"true"},{"option":"noOverlayEnlarged","type":"checkbox","value":"true"},{"option":"tileEnlargeStartEnlarged","type":"checkbox","value":"false"},{"option":"tileEnlargeShowButtonInactive","type":"checkbox","value":"true"},{"option":"tileEnlargeShowButtonActive","type":"checkbox","value":"true"},{"option":"tileEnlargeShowInPressureMenuInactive","type":"checkbox","value":"true"},{"option":"tileEnlargeShowInPressureMenuActive","type":"checkbox","value":"true"},{"option":"visibilityBackgroundURLEnlarged","type":"select","value":""},{"option":"hideDeviceNameIfEnlarged","type":"checkbox","value":"false"},{"option":"hideStateIfEnlarged","type":"checkbox","value":"false"},{"option":"hideIndicatorIfEnlarged","type":"checkbox","value":"false"},{"option":"hideInfoAIfEnlarged","type":"checkbox","value":"false"},{"option":"hideInfoBIfEnlarged","type":"checkbox","value":"false"},{"option":"hideIconEnlarged","type":"checkbox","value":"false"},{"option":"stateCaption","type":"text","value":""},{"option":"levelCaption","type":"text","value":""},{"option":"levelFavorites","type":"text","value":""},{"option":"levelFavoritesHideSlider","type":"checkbox","value":"false"},{"option":"addTimestampToState","type":"select","value":""},{"option":"hideStateAndLevelInDialog","type":"checkbox","value":"false"},{"option":"showTimestamp","type":"select","value":""},{"option":"infoARoundDigits","type":"number","value":"1"},{"option":"infoBRoundDigits","type":"number","value":"1"},{"option":"infoAShowName","type":"checkbox","value":"false"},{"option":"infoBShowName","type":"checkbox","value":"false"},{"option":"batteryIcon_on","type":"icon","value":""},{"option":"batteryActiveCondition","type":"select","value":""},{"option":"batteryActiveConditionValue","type":"text","value":""},{"option":"unreachIcon_on","type":"icon","value":""},{"option":"invertUnreach","type":"checkbox","value":"false"},{"option":"hideUnreachIfInactive","type":"checkbox","value":"false"},{"option":"errorIcon_on","type":"icon","value":""},{"option":"invertError","type":"checkbox","value":"false"},{"option":"adjustHeightToBackgroundView","type":"checkbox","value":"false"},{"option":"backgroundURLAllowAdjustHeight","type":"checkbox","value":"false"},{"option":"backgroundLimitAdjustHeightToScreen","type":"checkbox","value":"false"},{"option":"backgroundURLDynamicIframeZoom","type":"number","value":""},{"option":"backgroundURLPadding","type":"number","value":""},{"option":"backgroundURLAllowPostMessage","type":"checkbox","value":"false"},{"option":"backgroundURLNoPointerEvents","type":"checkbox","value":"false"},{"option":"overlayAboveBackgroundURL","type":"checkbox","value":"false"},{"option":"badgeWithoutUnit","type":"checkbox","value":"false"},{"option":"showBadgeIfZero","type":"checkbox","value":"false"},{"option":"invertGlowHide","type":"checkbox","value":"false"},{"option":"popupWidth","type":"number","value":""},{"option":"popupHeight","type":"number","value":""},{"option":"popupFixed","type":"checkbox","value":"false"},{"option":"openURLExternal","type":"checkbox","value":"false"},{"option":"openURLExternalCaption","type":"text","value":""},{"option":"popupAllowPostMessage","type":"checkbox","value":"false"},{"option":"additionalControlsSectionType","type":"select","value":"collapsible"},{"option":"additionalControlsCaption","type":"text","value":"Additional Controls"},{"option":"additionalControlsHeadingType","type":"select","value":"none"},{"option":"additionalControlsHideNameForButtons","type":"checkbox","value":"false"},{"option":"additionalInfoSectionType","type":"select","value":"collapsible"},{"option":"additionalInfoCaption","type":"text","value":"Additional Infos"},{"option":"additionalInfoListType","type":"select","value":""},{"option":"additionalInfoListColumnCount","type":"select","value":"auto"},{"option":"additionalInfoListColumnWidth","type":"number","value":""},{"option":"showStateAndLevelSeparatelyInTile","type":"select","value":""}]}]

Link zu externen Webseiten:

[{"commonName":"LINK Test","nativeNewLine":false,"nativeHeading":"","nativeHeadingOptions":"","nativeLinkedView":"","nativeBackgroundImage":"","nativeBackgroundImageActive":"","nativeHide":false,"commonRole":"iQontrolButton","states":[{"state":"STATE","commonRole":"linkedState","value":""},{"state":"SET_VALUE","commonRole":"const","value":""},{"state":"OFF_SET_VALUE","commonRole":"const","value":""},{"state":"INFO_A","commonRole":"array","value":"[]"},{"state":"INFO_B","commonRole":"array","value":"[]"},{"state":"BATTERY","commonRole":"linkedState","value":""},{"state":"UNREACH","commonRole":"linkedState","value":""},{"state":"ERROR","commonRole":"linkedState","value":""},{"state":"BACKGROUND_VIEW","commonRole":"const","value":""},{"state":"BACKGROUND_URL","commonRole":"const","value":""},{"state":"BACKGROUND_HTML","commonRole":"const","value":""},{"state":"ENLARGE_TILE","commonRole":"linkedState","value":""},{"state":"BADGE","commonRole":"linkedState","value":""},{"state":"BADGE_COLOR","commonRole":"const","value":""},{"state":"OVERLAY_INACTIVE_COLOR","commonRole":"const","value":""},{"state":"OVERLAY_ACTIVE_COLOR","commonRole":"const","value":""},{"state":"GLOW_INACTIVE_COLOR","commonRole":"const","value":""},{"state":"GLOW_ACTIVE_COLOR","commonRole":"const","value":""},{"state":"GLOW_HIDE","commonRole":"linkedState","value":""},{"state":"URL","commonRole":"const","value":"https://www.google.com"},{"state":"HTML","commonRole":"const","value":""},{"state":"ADDITIONAL_CONTROLS","commonRole":"array","value":"[]"},{"state":"ADDITIONAL_INFO","commonRole":"array","value":"[]"}],"options":[{"option":"icon_on","type":"icon","value":""},{"option":"icon_off","type":"icon","value":""},{"option":"readonly","type":"checkbox","value":"false"},{"option":"renderLinkedViewInParentInstance","type":"checkbox","value":"false"},{"option":"renderLinkedViewInParentInstanceClosesPanel","type":"checkbox","value":"false"},{"option":"clickOnIconAction","type":"select","value":"toggle"},{"option":"clickOnTileAction","type":"select","value":"openDialog"},{"option":"noZoomOnHover","type":"checkbox","value":"false"},{"option":"iconNoZoomOnHover","type":"checkbox","value":"false"},{"option":"hideDeviceName","type":"checkbox","value":"false"},{"option":"tileActiveStateId","type":"text","value":""},{"option":"tileActiveCondition","type":"select","value":""},{"option":"tileActiveConditionValue","type":"text","value":""},{"option":"sizeInactive","type":"select","value":""},{"option":"stateHeightAdaptsContentInactive","type":"checkbox","value":"false"},{"option":"stateFillsDeviceInactive","type":"checkbox","value":"false"},{"option":"stateBigFontInactive","type":"checkbox","value":"false"},{"option":"bigIconInactive","type":"checkbox","value":"false"},{"option":"iconNoPointerEventsInactive","type":"checkbox","value":"false"},{"option":"transparentIfInactive","type":"checkbox","value":"false"},{"option":"noOverlayInactive","type":"checkbox","value":"false"},{"option":"hideBackgroundURLInactive","type":"checkbox","value":"false"},{"option":"hideDeviceNameIfInactive","type":"checkbox","value":"false"},{"option":"hideStateIfInactive","type":"checkbox","value":"false"},{"option":"hideIndicatorIfInactive","type":"checkbox","value":"false"},{"option":"hideInfoAIfInactive","type":"checkbox","value":"false"},{"option":"hideInfoBIfInactive","type":"checkbox","value":"false"},{"option":"hideDeviceIfInactive","type":"checkbox","value":"false"},{"option":"sizeActive","type":"select","value":""},{"option":"stateHeightAdaptsContentActive","type":"checkbox","value":"false"},{"option":"stateFillsDeviceActive","type":"checkbox","value":"false"},{"option":"stateBigFontActive","type":"checkbox","value":"false"},{"option":"bigIconActive","type":"checkbox","value":"false"},{"option":"iconNoPointerEventsActive","type":"checkbox","value":"false"},{"option":"transparentIfActive","type":"checkbox","value":"false"},{"option":"noOverlayActive","type":"checkbox","value":"false"},{"option":"hideBackgroundURLActive","type":"checkbox","value":"false"},{"option":"hideDeviceNameIfActive","type":"checkbox","value":"false"},{"option":"hideStateIfActive","type":"checkbox","value":"false"},{"option":"hideIndicatorIfActive","type":"checkbox","value":"false"},{"option":"hideInfoAIfActive","type":"checkbox","value":"false"},{"option":"hideInfoBIfActive","type":"checkbox","value":"false"},{"option":"hideDeviceIfActive","type":"checkbox","value":"false"},{"option":"sizeEnlarged","type":"select","value":"fullWidthIfEnlarged fullHeightIfEnlarged"},{"option":"stateHeightAdaptsContentEnlarged","type":"checkbox","value":"false"},{"option":"stateFillsDeviceEnlarged","type":"checkbox","value":"false"},{"option":"stateBigFontEnlarged","type":"checkbox","value":"false"},{"option":"bigIconEnlarged","type":"checkbox","value":"true"},{"option":"iconNoPointerEventsEnlarged","type":"checkbox","value":"false"},{"option":"transparentIfEnlarged","type":"checkbox","value":"false"},{"option":"noOverlayEnlarged","type":"checkbox","value":"false"},{"option":"tileEnlargeStartEnlarged","type":"checkbox","value":"false"},{"option":"tileEnlargeShowButtonInactive","type":"checkbox","value":"false"},{"option":"tileEnlargeShowButtonActive","type":"checkbox","value":"false"},{"option":"tileEnlargeShowInPressureMenuInactive","type":"checkbox","value":"false"},{"option":"tileEnlargeShowInPressureMenuActive","type":"checkbox","value":"false"},{"option":"visibilityBackgroundURLEnlarged","type":"select","value":""},{"option":"hideDeviceNameIfEnlarged","type":"checkbox","value":"false"},{"option":"hideStateIfEnlarged","type":"checkbox","value":"false"},{"option":"hideIndicatorIfEnlarged","type":"checkbox","value":"false"},{"option":"hideInfoAIfEnlarged","type":"checkbox","value":"false"},{"option":"hideInfoBIfEnlarged","type":"checkbox","value":"false"},{"option":"hideIconEnlarged","type":"checkbox","value":"false"},{"option":"stateCaption","type":"text","value":""},{"option":"addTimestampToState","type":"select","value":""},{"option":"hideStateAndLevelInDialog","type":"checkbox","value":"false"},{"option":"showTimestamp","type":"select","value":""},{"option":"infoARoundDigits","type":"number","value":"1"},{"option":"infoBRoundDigits","type":"number","value":"1"},{"option":"infoAShowName","type":"checkbox","value":"false"},{"option":"infoBShowName","type":"checkbox","value":"false"},{"option":"batteryIcon_on","type":"icon","value":""},{"option":"batteryActiveCondition","type":"select","value":""},{"option":"batteryActiveConditionValue","type":"text","value":""},{"option":"unreachIcon_on","type":"icon","value":""},{"option":"invertUnreach","type":"checkbox","value":"false"},{"option":"hideUnreachIfInactive","type":"checkbox","value":"false"},{"option":"errorIcon_on","type":"icon","value":""},{"option":"invertError","type":"checkbox","value":"false"},{"option":"adjustHeightToBackgroundView","type":"checkbox","value":"false"},{"option":"backgroundURLAllowAdjustHeight","type":"checkbox","value":"false"},{"option":"backgroundLimitAdjustHeightToScreen","type":"checkbox","value":"false"},{"option":"backgroundURLDynamicIframeZoom","type":"number","value":""},{"option":"backgroundURLPadding","type":"number","value":""},{"option":"backgroundURLAllowPostMessage","type":"checkbox","value":"false"},{"option":"backgroundURLNoPointerEvents","type":"checkbox","value":"false"},{"option":"overlayAboveBackgroundURL","type":"checkbox","value":"false"},{"option":"badgeWithoutUnit","type":"checkbox","value":"false"},{"option":"showBadgeIfZero","type":"checkbox","value":"false"},{"option":"invertGlowHide","type":"checkbox","value":"false"},{"option":"popupWidth","type":"number","value":""},{"option":"popupHeight","type":"number","value":""},{"option":"popupFixed","type":"checkbox","value":"false"},{"option":"openURLExternal","type":"checkbox","value":"true"},{"option":"openURLExternalCaption","type":"text","value":""},{"option":"popupAllowPostMessage","type":"checkbox","value":"false"},{"option":"additionalControlsSectionType","type":"select","value":"collapsible"},{"option":"additionalControlsCaption","type":"text","value":"Additional Controls"},{"option":"additionalControlsHeadingType","type":"select","value":"none"},{"option":"additionalControlsHideNameForButtons","type":"checkbox","value":"false"},{"option":"additionalInfoSectionType","type":"select","value":"collapsible"},{"option":"additionalInfoCaption","type":"text","value":"Additional Infos"},{"option":"additionalInfoListType","type":"select","value":""},{"option":"additionalInfoListColumnCount","type":"select","value":"auto"},{"option":"additionalInfoListColumnWidth","type":"number","value":""},{"option":"showState","type":"checkbox","value":"false"},{"option":"buttonCaption","type":"text","value":""},{"option":"returnToOffSetValueAfter","type":"number","value":""},{"option":"closeDialogAfterExecution","type":"checkbox","value":"false"}]}]

Wetter:

Info von einem anderen Zuschauer, damit die Daten nicht drei mal dargestellt werden: Der Text im Wetterwidget wird nicht 3 mal angezeigt, wenn man im Link die Anweisung “async” entfernt.

[{"commonName":"Wetter","nativeNewLine":true,"nativeHeading":"","nativeHeadingOptions":"","nativeLinkedView":"","nativeBackgroundImage":"","nativeBackgroundImageActive":"","nativeHide":false,"commonRole":"iQontrolPopup","states":[{"state":"STATE","commonRole":"linkedState","value":""},{"state":"INFO_A","commonRole":"array","value":"[]"},{"state":"INFO_B","commonRole":"array","value":"[]"},{"state":"BATTERY","commonRole":"linkedState","value":""},{"state":"UNREACH","commonRole":"linkedState","value":""},{"state":"ERROR","commonRole":"linkedState","value":""},{"state":"BACKGROUND_VIEW","commonRole":"const","value":""},{"state":"BACKGROUND_URL","commonRole":"const","value":""},{"state":"BACKGROUND_HTML","commonRole":"const","value":"<div id=\"cont_5b860c1d84b6eb5817bf7406f61232f1\"><script type=\"text/javascript\" async src=\"https://www.daswetter.com/wid_loader/5b860c1d84b6eb5817bf7406f61232f1\"></script></div>"},{"state":"ENLARGE_TILE","commonRole":"linkedState","value":""},{"state":"BADGE","commonRole":"linkedState","value":""},{"state":"BADGE_COLOR","commonRole":"const","value":""},{"state":"OVERLAY_INACTIVE_COLOR","commonRole":"const","value":""},{"state":"OVERLAY_ACTIVE_COLOR","commonRole":"const","value":""},{"state":"GLOW_INACTIVE_COLOR","commonRole":"const","value":""},{"state":"GLOW_ACTIVE_COLOR","commonRole":"const","value":""},{"state":"GLOW_HIDE","commonRole":"linkedState","value":""},{"state":"URL","commonRole":"const","value":""},{"state":"HTML","commonRole":"const","value":""},{"state":"ADDITIONAL_CONTROLS","commonRole":"array","value":"[]"},{"state":"ADDITIONAL_INFO","commonRole":"array","value":"[]"}],"options":[{"option":"icon_on","type":"icon","value":""},{"option":"icon_off","type":"icon","value":""},{"option":"readonly","type":"checkbox","value":"true"},{"option":"renderLinkedViewInParentInstance","type":"checkbox","value":"false"},{"option":"renderLinkedViewInParentInstanceClosesPanel","type":"checkbox","value":"false"},{"option":"clickOnIconAction","type":"select","value":"false"},{"option":"clickOnTileAction","type":"select","value":"false"},{"option":"noZoomOnHover","type":"checkbox","value":"true"},{"option":"iconNoZoomOnHover","type":"checkbox","value":"false"},{"option":"hideDeviceName","type":"checkbox","value":"true"},{"option":"tileActiveStateId","type":"text","value":""},{"option":"tileActiveCondition","type":"select","value":"at"},{"option":"tileActiveConditionValue","type":"text","value":""},{"option":"sizeInactive","type":"select","value":""},{"option":"stateHeightAdaptsContentInactive","type":"checkbox","value":"false"},{"option":"stateFillsDeviceInactive","type":"checkbox","value":"false"},{"option":"stateBigFontInactive","type":"checkbox","value":"false"},{"option":"bigIconInactive","type":"checkbox","value":"false"},{"option":"iconNoPointerEventsInactive","type":"checkbox","value":"false"},{"option":"transparentIfInactive","type":"checkbox","value":"false"},{"option":"noOverlayInactive","type":"checkbox","value":"false"},{"option":"hideBackgroundURLInactive","type":"checkbox","value":"false"},{"option":"hideDeviceNameIfInactive","type":"checkbox","value":"false"},{"option":"hideStateIfInactive","type":"checkbox","value":"false"},{"option":"hideIndicatorIfInactive","type":"checkbox","value":"false"},{"option":"hideInfoAIfInactive","type":"checkbox","value":"false"},{"option":"hideInfoBIfInactive","type":"checkbox","value":"false"},{"option":"hideDeviceIfInactive","type":"checkbox","value":"false"},{"option":"sizeActive","type":"select","value":"xwideIfActive highIfActive"},{"option":"stateHeightAdaptsContentActive","type":"checkbox","value":"false"},{"option":"stateFillsDeviceActive","type":"checkbox","value":"false"},{"option":"stateBigFontActive","type":"checkbox","value":"false"},{"option":"bigIconActive","type":"checkbox","value":"false"},{"option":"iconNoPointerEventsActive","type":"checkbox","value":"false"},{"option":"transparentIfActive","type":"checkbox","value":"false"},{"option":"noOverlayActive","type":"checkbox","value":"true"},{"option":"hideBackgroundURLActive","type":"checkbox","value":"false"},{"option":"hideDeviceNameIfActive","type":"checkbox","value":"false"},{"option":"hideStateIfActive","type":"checkbox","value":"true"},{"option":"hideIndicatorIfActive","type":"checkbox","value":"false"},{"option":"hideInfoAIfActive","type":"checkbox","value":"false"},{"option":"hideInfoBIfActive","type":"checkbox","value":"false"},{"option":"hideDeviceIfActive","type":"checkbox","value":"false"},{"option":"sizeEnlarged","type":"select","value":"fullWidthIfEnlarged fullHeightIfEnlarged"},{"option":"stateHeightAdaptsContentEnlarged","type":"checkbox","value":"false"},{"option":"stateFillsDeviceEnlarged","type":"checkbox","value":"false"},{"option":"stateBigFontEnlarged","type":"checkbox","value":"false"},{"option":"bigIconEnlarged","type":"checkbox","value":"true"},{"option":"iconNoPointerEventsEnlarged","type":"checkbox","value":"false"},{"option":"transparentIfEnlarged","type":"checkbox","value":"false"},{"option":"noOverlayEnlarged","type":"checkbox","value":"false"},{"option":"tileEnlargeStartEnlarged","type":"checkbox","value":"false"},{"option":"tileEnlargeShowButtonInactive","type":"checkbox","value":"false"},{"option":"tileEnlargeShowButtonActive","type":"checkbox","value":"false"},{"option":"tileEnlargeShowInPressureMenuInactive","type":"checkbox","value":"false"},{"option":"tileEnlargeShowInPressureMenuActive","type":"checkbox","value":"false"},{"option":"visibilityBackgroundURLEnlarged","type":"select","value":""},{"option":"hideDeviceNameIfEnlarged","type":"checkbox","value":"false"},{"option":"hideStateIfEnlarged","type":"checkbox","value":"false"},{"option":"hideIndicatorIfEnlarged","type":"checkbox","value":"false"},{"option":"hideInfoAIfEnlarged","type":"checkbox","value":"false"},{"option":"hideInfoBIfEnlarged","type":"checkbox","value":"false"},{"option":"hideIconEnlarged","type":"checkbox","value":"false"},{"option":"stateCaption","type":"text","value":""},{"option":"addTimestampToState","type":"select","value":""},{"option":"hideStateAndLevelInDialog","type":"checkbox","value":"false"},{"option":"showTimestamp","type":"select","value":""},{"option":"infoARoundDigits","type":"number","value":"1"},{"option":"infoBRoundDigits","type":"number","value":"1"},{"option":"infoAShowName","type":"checkbox","value":"false"},{"option":"infoBShowName","type":"checkbox","value":"false"},{"option":"batteryIcon_on","type":"icon","value":""},{"option":"batteryActiveCondition","type":"select","value":""},{"option":"batteryActiveConditionValue","type":"text","value":""},{"option":"unreachIcon_on","type":"icon","value":""},{"option":"invertUnreach","type":"checkbox","value":"false"},{"option":"hideUnreachIfInactive","type":"checkbox","value":"false"},{"option":"errorIcon_on","type":"icon","value":""},{"option":"invertError","type":"checkbox","value":"false"},{"option":"adjustHeightToBackgroundView","type":"checkbox","value":"false"},{"option":"backgroundURLAllowAdjustHeight","type":"checkbox","value":"false"},{"option":"backgroundLimitAdjustHeightToScreen","type":"checkbox","value":"false"},{"option":"backgroundURLDynamicIframeZoom","type":"number","value":""},{"option":"backgroundURLPadding","type":"number","value":""},{"option":"backgroundURLAllowPostMessage","type":"checkbox","value":"false"},{"option":"backgroundURLNoPointerEvents","type":"checkbox","value":"false"},{"option":"overlayAboveBackgroundURL","type":"checkbox","value":"false"},{"option":"badgeWithoutUnit","type":"checkbox","value":"false"},{"option":"showBadgeIfZero","type":"checkbox","value":"false"},{"option":"invertGlowHide","type":"checkbox","value":"false"},{"option":"popupWidth","type":"number","value":"305"},{"option":"popupHeight","type":"number","value":"217"},{"option":"popupFixed","type":"checkbox","value":"true"},{"option":"openURLExternal","type":"checkbox","value":"false"},{"option":"openURLExternalCaption","type":"text","value":""},{"option":"popupAllowPostMessage","type":"checkbox","value":"false"},{"option":"additionalControlsSectionType","type":"select","value":"collapsible"},{"option":"additionalControlsCaption","type":"text","value":"Additional Controls"},{"option":"additionalControlsHeadingType","type":"select","value":"none"},{"option":"additionalControlsHideNameForButtons","type":"checkbox","value":"false"},{"option":"additionalInfoSectionType","type":"select","value":"collapsible"},{"option":"additionalInfoCaption","type":"text","value":"Additional Infos"},{"option":"additionalInfoListType","type":"select","value":""},{"option":"additionalInfoListColumnCount","type":"select","value":"auto"},{"option":"additionalInfoListColumnWidth","type":"number","value":""}]}]

Diagramme

[{"commonName":"Flot-chart","commonRole":"iQontrolWidget","nativeBackgroundImage":"","nativeBackgroundImageActive":"","nativeHeading":"","nativeLinkedView":"","nativeNewLine":true,"options":[{"option":"icon_on","type":"icon","value":""},{"option":"icon_off","type":"icon","value":""},{"option":"readonly","type":"checkbox","value":"false"},{"option":"renderLinkedViewInParentInstance","type":"checkbox","value":"false"},{"option":"renderLinkedViewInParentInstanceClosesPanel","type":"checkbox","value":"false"},{"option":"clickOnIconAction","type":"select","value":"toggle"},{"option":"clickOnTileAction","type":"select","value":"openDialog"},{"option":"noZoomOnHover","type":"checkbox","value":"true"},{"option":"iconNoZoomOnHover","type":"checkbox","value":"false"},{"option":"hideDeviceName","type":"checkbox","value":"true"},{"option":"tileActiveStateId","type":"text","value":""},{"option":"tileActiveCondition","type":"select","value":""},{"option":"tileActiveConditionValue","type":"text","value":""},{"option":"sizeInactive","type":"select","value":"xwideIfInactive highIfInactive"},{"option":"stateHeightAdaptsContentInactive","type":"checkbox","value":"false"},{"option":"stateFillsDeviceInactive","type":"checkbox","value":"false"},{"option":"stateBigFontInactive","type":"checkbox","value":"false"},{"option":"bigIconInactive","type":"checkbox","value":"false"},{"option":"iconNoPointerEventsInactive","type":"checkbox","value":"false"},{"option":"transparentIfInactive","type":"checkbox","value":"false"},{"option":"noOverlayInactive","type":"checkbox","value":"true"},{"option":"hideBackgroundURLInactive","type":"checkbox","value":"false"},{"option":"hideDeviceNameIfInactive","type":"checkbox","value":"false"},{"option":"hideStateIfInactive","type":"checkbox","value":"true"},{"option":"hideIndicatorIfInactive","type":"checkbox","value":"false"},{"option":"hideInfoAIfInactive","type":"checkbox","value":"false"},{"option":"hideInfoBIfInactive","type":"checkbox","value":"false"},{"option":"hideDeviceIfInactive","type":"checkbox","value":"false"},{"option":"sizeActive","type":"select","value":"fullWidthIfActive fullHeightIfActive"},{"option":"stateHeightAdaptsContentActive","type":"checkbox","value":"false"},{"option":"stateFillsDeviceActive","type":"checkbox","value":"false"},{"option":"stateBigFontActive","type":"checkbox","value":"false"},{"option":"bigIconActive","type":"checkbox","value":"false"},{"option":"iconNoPointerEventsActive","type":"checkbox","value":"false"},{"option":"transparentIfActive","type":"checkbox","value":"false"},{"option":"noOverlayActive","type":"checkbox","value":"true"},{"option":"hideBackgroundURLActive","type":"checkbox","value":"false"},{"option":"hideDeviceNameIfActive","type":"checkbox","value":"false"},{"option":"hideStateIfActive","type":"checkbox","value":"false"},{"option":"hideIndicatorIfActive","type":"checkbox","value":"false"},{"option":"hideInfoAIfActive","type":"checkbox","value":"false"},{"option":"hideInfoBIfActive","type":"checkbox","value":"false"},{"option":"hideDeviceIfActive","type":"checkbox","value":"false"},{"option":"sizeEnlarged","type":"select","value":"fullWidthIfEnlarged fullHeightIfEnlarged"},{"option":"stateHeightAdaptsContentEnlarged","type":"checkbox","value":"false"},{"option":"stateFillsDeviceEnlarged","type":"checkbox","value":"false"},{"option":"stateBigFontEnlarged","type":"checkbox","value":"false"},{"option":"bigIconEnlarged","type":"checkbox","value":"true"},{"option":"iconNoPointerEventsEnlarged","type":"checkbox","value":"false"},{"option":"transparentIfEnlarged","type":"checkbox","value":"false"},{"option":"noOverlayEnlarged","type":"checkbox","value":"false"},{"option":"tileEnlargeStartEnlarged","type":"checkbox","value":"false"},{"option":"tileEnlargeShowButtonInactive","type":"checkbox","value":"true"},{"option":"tileEnlargeShowButtonActive","type":"checkbox","value":"true"},{"option":"tileEnlargeShowInPressureMenuInactive","type":"checkbox","value":"true"},{"option":"tileEnlargeShowInPressureMenuActive","type":"checkbox","value":"true"},{"option":"visibilityBackgroundURLEnlarged","type":"select","value":""},{"option":"hideDeviceNameIfEnlarged","type":"checkbox","value":"false"},{"option":"hideStateIfEnlarged","type":"checkbox","value":"false"},{"option":"hideIndicatorIfEnlarged","type":"checkbox","value":"false"},{"option":"hideInfoAIfEnlarged","type":"checkbox","value":"false"},{"option":"hideInfoBIfEnlarged","type":"checkbox","value":"false"},{"option":"hideIconEnlarged","type":"checkbox","value":"false"},{"option":"stateCaption","type":"text","value":""},{"option":"addTimestampToState","type":"select","value":"N"},{"option":"hideStateAndLevelInDialog","type":"checkbox","value":"false"},{"option":"showTimestamp","type":"select","value":""},{"option":"infoARoundDigits","type":"number","value":"1"},{"option":"infoBRoundDigits","type":"number","value":"1"},{"option":"infoAShowName","type":"checkbox","value":"false"},{"option":"infoBShowName","type":"checkbox","value":"false"},{"option":"batteryIcon_on","type":"icon","value":""},{"option":"batteryActiveCondition","type":"select","value":""},{"option":"batteryActiveConditionValue","type":"text","value":""},{"option":"unreachIcon_on","type":"icon","value":""},{"option":"invertUnreach","type":"checkbox","value":"false"},{"option":"hideUnreachIfInactive","type":"checkbox","value":"false"},{"option":"errorIcon_on","type":"icon","value":""},{"option":"invertError","type":"checkbox","value":"false"},{"option":"adjustHeightToBackgroundView","type":"checkbox","value":"false"},{"option":"backgroundURLAllowAdjustHeight","type":"checkbox","value":"false"},{"option":"backgroundLimitAdjustHeightToScreen","type":"checkbox","value":"false"},{"option":"backgroundURLDynamicIframeZoom","type":"number","value":""},{"option":"backgroundURLPadding","type":"number","value":""},{"option":"backgroundURLAllowPostMessage","type":"checkbox","value":"true"},{"option":"backgroundURLNoPointerEvents","type":"checkbox","value":"true"},{"option":"overlayAboveBackgroundURL","type":"checkbox","value":"false"},{"option":"badgeWithoutUnit","type":"checkbox","value":"false"},{"option":"showBadgeIfZero","type":"checkbox","value":"false"},{"option":"invertGlowHide","type":"checkbox","value":"false"},{"option":"popupWidth","type":"number","value":""},{"option":"popupHeight","type":"number","value":""},{"option":"popupFixed","type":"checkbox","value":"false"},{"option":"openURLExternal","type":"checkbox","value":"false"},{"option":"openURLExternalCaption","type":"text","value":""},{"option":"popupAllowPostMessage","type":"checkbox","value":"true"},{"option":"additionalControlsSectionType","type":"select","value":"collapsible"},{"option":"additionalControlsCaption","type":"text","value":"Additional Controls"},{"option":"additionalControlsHeadingType","type":"select","value":"none"},{"option":"additionalControlsHideNameForButtons","type":"checkbox","value":"false"},{"option":"additionalInfoSectionType","type":"select","value":"collapsible"},{"option":"additionalInfoCaption","type":"text","value":"Additional Infos"},{"option":"additionalInfoListType","type":"select","value":""},{"option":"additionalInfoListColumnCount","type":"select","value":"auto"},{"option":"additionalInfoListColumnWidth","type":"number","value":""},{"option":"noVirtualState","type":"checkbox","value":"false"}],"states":[{"state":"STATE","commonRole":"linkedState","value":""},{"state":"INFO_A","commonRole":"array","value":"[]"},{"state":"INFO_B","commonRole":"array","value":"[]"},{"state":"BATTERY","commonRole":"linkedState","value":""},{"state":"UNREACH","commonRole":"linkedState","value":""},{"state":"ERROR","commonRole":"linkedState","value":""},{"state":"BACKGROUND_VIEW","commonRole":"const","value":""},{"state":"BACKGROUND_URL","commonRole":"const","value":"./images/widgets/flot-chart/flot-chart.html?chartColor=rgb%28104%2C164%2C255%29&fill=0.25&range=357&min=&max=&ignoreMinMax=false&fullScreen=false&showXaxe=bottom&xticks=3&showYaxe=left&yticks=0&useThisDatapoint=alias.0.Wetterdaten.Windgeschwindigkeit&historyInstance=history.0&useThisDatapoint2=&chartColor2=rgba%28255%2C0%2C0%2C0.5%29&fill2=0.05&useMinMaxFromMain2=true&min2=&max2=&ignoreMinMax2=false&useThisDatapoint3=&chartColor3=rgba%28255%2C200%2C0%2C0.5%29&fill3=0.05&useMinMaxFromMain3=true&min3=&max3=&ignoreMinMax3=false"},{"state":"BACKGROUND_HTML","commonRole":"const","value":""},{"state":"ENLARGE_TILE","commonRole":"linkedState","value":""},{"state":"BADGE","commonRole":"linkedState","value":""},{"state":"BADGE_COLOR","commonRole":"const","value":""},{"state":"OVERLAY_INACTIVE_COLOR","commonRole":"const","value":""},{"state":"OVERLAY_ACTIVE_COLOR","commonRole":"const","value":""},{"state":"GLOW_INACTIVE_COLOR","commonRole":"const","value":""},{"state":"GLOW_ACTIVE_COLOR","commonRole":"const","value":""},{"state":"GLOW_HIDE","commonRole":"linkedState","value":""},{"state":"URL","commonRole":"const","value":""},{"state":"HTML","commonRole":"const","value":""},{"state":"ADDITIONAL_CONTROLS","commonRole":"array","value":"[]"},{"state":"ADDITIONAL_INFO","commonRole":"array","value":"[]"}],"nativeHeadingOptions":""}]

Eigene Daten – Hier das Beispiel zum Batteriespeicher:

[{"commonName":"Batteriespeicher","nativeNewLine":false,"nativeHeading":"","nativeHeadingOptions":"","nativeLinkedView":"","nativeBackgroundImage":"","nativeBackgroundImageActive":"","nativeHide":false,"commonRole":"iQontrolValue","states":[{"state":"STATE","commonRole":"linkedState","value":""},{"state":"LEVEL","commonRole":"linkedState","value":"alias.0.Variablen.Energie.prozent_Batterieladung"},{"state":"INFO_A","commonRole":"array","value":"[]"},{"state":"INFO_B","commonRole":"array","value":"[]"},{"state":"BATTERY","commonRole":"linkedState","value":""},{"state":"UNREACH","commonRole":"linkedState","value":""},{"state":"ERROR","commonRole":"linkedState","value":""},{"state":"BACKGROUND_VIEW","commonRole":"const","value":""},{"state":"BACKGROUND_URL","commonRole":"const","value":""},{"state":"BACKGROUND_HTML","commonRole":"const","value":""},{"state":"ENLARGE_TILE","commonRole":"linkedState","value":""},{"state":"BADGE","commonRole":"linkedState","value":""},{"state":"BADGE_COLOR","commonRole":"const","value":""},{"state":"OVERLAY_INACTIVE_COLOR","commonRole":"const","value":""},{"state":"OVERLAY_ACTIVE_COLOR","commonRole":"const","value":""},{"state":"GLOW_INACTIVE_COLOR","commonRole":"const","value":""},{"state":"GLOW_ACTIVE_COLOR","commonRole":"const","value":""},{"state":"GLOW_HIDE","commonRole":"linkedState","value":""},{"state":"URL","commonRole":"const","value":""},{"state":"HTML","commonRole":"const","value":""},{"state":"ADDITIONAL_CONTROLS","commonRole":"array","value":"[]"},{"state":"ADDITIONAL_INFO","commonRole":"array","value":"[]"}],"options":[{"option":"icon_on","type":"icon","value":"./images/icons/battery_75.png"},{"option":"icon_off","type":"icon","value":"./images/icons/battery_75.png"},{"option":"readonly","type":"checkbox","value":"true"},{"option":"renderLinkedViewInParentInstance","type":"checkbox","value":"false"},{"option":"renderLinkedViewInParentInstanceClosesPanel","type":"checkbox","value":"false"},{"option":"clickOnIconAction","type":"select","value":"false"},{"option":"clickOnTileAction","type":"select","value":"false"},{"option":"noZoomOnHover","type":"checkbox","value":"false"},{"option":"iconNoZoomOnHover","type":"checkbox","value":"false"},{"option":"hideDeviceName","type":"checkbox","value":"false"},{"option":"tileActiveStateId","type":"text","value":""},{"option":"tileActiveCondition","type":"select","value":""},{"option":"tileActiveConditionValue","type":"text","value":""},{"option":"sizeInactive","type":"select","value":""},{"option":"stateHeightAdaptsContentInactive","type":"checkbox","value":"false"},{"option":"stateFillsDeviceInactive","type":"checkbox","value":"false"},{"option":"stateBigFontInactive","type":"checkbox","value":"false"},{"option":"bigIconInactive","type":"checkbox","value":"false"},{"option":"iconNoPointerEventsInactive","type":"checkbox","value":"false"},{"option":"transparentIfInactive","type":"checkbox","value":"false"},{"option":"noOverlayInactive","type":"checkbox","value":"false"},{"option":"hideBackgroundURLInactive","type":"checkbox","value":"false"},{"option":"hideDeviceNameIfInactive","type":"checkbox","value":"false"},{"option":"hideStateIfInactive","type":"checkbox","value":"false"},{"option":"hideIndicatorIfInactive","type":"checkbox","value":"false"},{"option":"hideInfoAIfInactive","type":"checkbox","value":"false"},{"option":"hideInfoBIfInactive","type":"checkbox","value":"false"},{"option":"hideDeviceIfInactive","type":"checkbox","value":"false"},{"option":"sizeActive","type":"select","value":""},{"option":"stateHeightAdaptsContentActive","type":"checkbox","value":"false"},{"option":"stateFillsDeviceActive","type":"checkbox","value":"false"},{"option":"stateBigFontActive","type":"checkbox","value":"false"},{"option":"bigIconActive","type":"checkbox","value":"false"},{"option":"iconNoPointerEventsActive","type":"checkbox","value":"false"},{"option":"transparentIfActive","type":"checkbox","value":"false"},{"option":"noOverlayActive","type":"checkbox","value":"false"},{"option":"hideBackgroundURLActive","type":"checkbox","value":"false"},{"option":"hideDeviceNameIfActive","type":"checkbox","value":"false"},{"option":"hideStateIfActive","type":"checkbox","value":"false"},{"option":"hideIndicatorIfActive","type":"checkbox","value":"false"},{"option":"hideInfoAIfActive","type":"checkbox","value":"false"},{"option":"hideInfoBIfActive","type":"checkbox","value":"false"},{"option":"hideDeviceIfActive","type":"checkbox","value":"false"},{"option":"sizeEnlarged","type":"select","value":"fullWidthIfEnlarged fullHeightIfEnlarged"},{"option":"stateHeightAdaptsContentEnlarged","type":"checkbox","value":"false"},{"option":"stateFillsDeviceEnlarged","type":"checkbox","value":"false"},{"option":"stateBigFontEnlarged","type":"checkbox","value":"false"},{"option":"bigIconEnlarged","type":"checkbox","value":"true"},{"option":"iconNoPointerEventsEnlarged","type":"checkbox","value":"false"},{"option":"transparentIfEnlarged","type":"checkbox","value":"false"},{"option":"noOverlayEnlarged","type":"checkbox","value":"false"},{"option":"tileEnlargeStartEnlarged","type":"checkbox","value":"false"},{"option":"tileEnlargeShowButtonInactive","type":"checkbox","value":"false"},{"option":"tileEnlargeShowButtonActive","type":"checkbox","value":"false"},{"option":"tileEnlargeShowInPressureMenuInactive","type":"checkbox","value":"false"},{"option":"tileEnlargeShowInPressureMenuActive","type":"checkbox","value":"false"},{"option":"visibilityBackgroundURLEnlarged","type":"select","value":""},{"option":"hideDeviceNameIfEnlarged","type":"checkbox","value":"false"},{"option":"hideStateIfEnlarged","type":"checkbox","value":"false"},{"option":"hideIndicatorIfEnlarged","type":"checkbox","value":"false"},{"option":"hideInfoAIfEnlarged","type":"checkbox","value":"false"},{"option":"hideInfoBIfEnlarged","type":"checkbox","value":"false"},{"option":"hideIconEnlarged","type":"checkbox","value":"false"},{"option":"stateCaption","type":"text","value":""},{"option":"levelCaption","type":"text","value":""},{"option":"levelFavorites","type":"text","value":""},{"option":"addTimestampToState","type":"select","value":""},{"option":"hideStateAndLevelInDialog","type":"checkbox","value":"false"},{"option":"showTimestamp","type":"select","value":""},{"option":"infoARoundDigits","type":"number","value":"1"},{"option":"infoBRoundDigits","type":"number","value":"1"},{"option":"infoAShowName","type":"checkbox","value":"false"},{"option":"infoBShowName","type":"checkbox","value":"false"},{"option":"batteryIcon_on","type":"icon","value":""},{"option":"batteryActiveCondition","type":"select","value":""},{"option":"batteryActiveConditionValue","type":"text","value":""},{"option":"unreachIcon_on","type":"icon","value":""},{"option":"invertUnreach","type":"checkbox","value":"false"},{"option":"hideUnreachIfInactive","type":"checkbox","value":"false"},{"option":"errorIcon_on","type":"icon","value":""},{"option":"invertError","type":"checkbox","value":"false"},{"option":"adjustHeightToBackgroundView","type":"checkbox","value":"false"},{"option":"backgroundURLAllowAdjustHeight","type":"checkbox","value":"false"},{"option":"backgroundLimitAdjustHeightToScreen","type":"checkbox","value":"false"},{"option":"backgroundURLDynamicIframeZoom","type":"number","value":""},{"option":"backgroundURLPadding","type":"number","value":""},{"option":"backgroundURLAllowPostMessage","type":"checkbox","value":"false"},{"option":"backgroundURLNoPointerEvents","type":"checkbox","value":"false"},{"option":"overlayAboveBackgroundURL","type":"checkbox","value":"false"},{"option":"badgeWithoutUnit","type":"checkbox","value":"false"},{"option":"invertGlowHide","type":"checkbox","value":"false"},{"option":"popupWidth","type":"number","value":""},{"option":"popupHeight","type":"number","value":""},{"option":"popupFixed","type":"checkbox","value":"false"},{"option":"openURLExternal","type":"checkbox","value":"false"},{"option":"openURLExternalCaption","type":"text","value":""},{"option":"popupAllowPostMessage","type":"checkbox","value":"false"},{"option":"additionalControlsSectionType","type":"select","value":"collapsible"},{"option":"additionalControlsCaption","type":"text","value":"Additional Controls"},{"option":"additionalControlsHeadingType","type":"select","value":"none"},{"option":"additionalControlsHideNameForButtons","type":"checkbox","value":"false"},{"option":"additionalInfoSectionType","type":"select","value":"collapsible"},{"option":"additionalInfoCaption","type":"text","value":"Additional Infos"},{"option":"additionalInfoListType","type":"select","value":""},{"option":"additionalInfoListColumnCount","type":"select","value":"auto"},{"option":"additionalInfoListColumnWidth","type":"number","value":""},{"option":"showStateAndLevelSeparatelyInTile","type":"select","value":""}]}]

Vielleicht auch interessant?

Beitrag teilen:

3 Kommentare. Hinterlasse eine Antwort

  • Günter Ohl
    5. November 2023 9:57

    Hallo Stefan,

    habe 3 Fragen:
    F1: Wenn ich auf dem Tablet die VIS 1 vom ioBroker installiert habe, kann ich auf dem gleichen Tablet auch parallel iQontrol installiere
    und einrichten?
    F2: Kann ich von der VIS1 Oberfläche durch einen Button auf der Homeseite auf die Oberfläche von iQontrol wechseln?
    F3: Gibt es für iQontrol auch andere Wigdets die optisch mit denen der VIS1 mithalten können oder vergleichbar sind?

    Vielen Dank für Deine Infos

    LG Günter

    • Hallo! Hier gern Deine Antworten:
      1. Klar – aber iQontrol muss nicht installiert werden. Einfach einen Browser öffnen und los geht’s
      2. Das geht natürlich. Einfach einen Link einfügen der auf die Seite von iQontrol verweisst.
      3. Soweit ich weiss nicht.

  • Rolf Becker
    25. Januar 2024 11:12

    Hi Stefan,
    ich konnte sehr vieles ohne großen Aufwand in IQontrol einbinden, aber wo ich gar nicht voran komme, ist dieses Gerät: hm-lc-dim1tpbu-fm
    Es wird als Licht erkannt und angelegt (automatisch erstell) aber er schaltet es nicht. Wenn ich es neu erstelle und es nicht automatisch erstellen lasse, geht es auch nicht.
    Hattest du auch mal so ein problem oder kannst helfen?

    MfG Benjamin
